ADATOK
CONTROL AND ELECTRONICS:
NCT 304/19" smart touch CNC
Main spindle braking with regenerative feedback
EnDat 2.2 absolute measuring system, 0.00005 mm positioning resolution, nano interpolation
WARRANTY AND CE:
36 moths warranty for the CNC and for all the electric parts of the machine
12-month warranty on machine mechanics
CE compliance

MŰSZAKI SPECIFIKÁCIÓK
WORKING AREA:
Max. swing diameter over bed	550 mm
Maximum turning diameter	350 mm
Maximum turning length	500 mm
Recommended chuck diameter	8"
AXIS:
Type of Guideway	Linear
X stroke/travel	210 mm
Z stroke/travel	550 mm
W stroke/travel	590 mm
X / Z / Y / W rapid speed	24/24/X/24 mpm
SPINDLE:
Spindle nose	A2-6
Spindle bore diameter	71 mm
Main spindle bar capacity	50 mm
Number of ranges	1
SPINDLE MOTOR:
Spindle motor torque	140 Nm
SUBSPINDLE:
Maximum spindle speed	5000 RPM
Subspindle nose / Recommended chuck diameter	A2-5 / 6" mm
Subspindle bore diameter	48 mm
TAILSTOCK:
TOOLING:
Tool change	Turret
Number of tool positions	12 pc
Tooling	BMT55
Operation	Servo
Number of driven tools	12 pc
Maximum speed of tool	5000 RPM
INSTALLATION:
Floor space × height	3148 × 1926 × 1860 mm
Net machine weight	5350 kg
Electrical connection	3 × 400 V AC VA

ALAPTARTOZÉKOK ÉS OPCIÓK
Power operated three-jaws chuck
Subspindle
Leveling feet and bolts
Machine lamp
category	10
BMT tooling turret
Servo turret, controlable tool change speed
CONTROL AND ELECTRONICS:
NCT 304 Controller 19" touchscreen
Built-in, swivel control panel
Builtin handwheel
Second-stage rapid traverse for spindle and axes
myNCT graphical programing
CAD-CAM software
Machine shutdown from technological program
Three-color status signal lamp
Green technology
NCT simulator
Remote machine access
Dual-channel controller
SERVICES:
1+1 days training
Installation and commissioning
NCT customer support
NCT service support
NCT telephone technological support
Machine transport, loading, machine relocation
Workpiece process development
Training and courses (NCT Academy)
OPTIONS:
Hydraulically operated chuck
Tool touch probe (manual or automatic)
Workpiece Touch probe (infra)
Workpiece catcher and conveyor
Chain-type chip conveyor
Through-tool coolant
Program-controlled coolant pressure
Oil skimmer
Mist extractor
Automatic door actuation
Robot cell interface
