Specifications
| ADATOK | |
| CONTROL AND ELECTRONICS: | |
| NCT 304/19" smart touch CNC | |
| Main spindle braking with braking resistor | |
| Main spindle braking with regenerative feedback | |
| EnDat 2.2 absolute measuring system, 0.00005 mm positioning resolution, nano interpolation | |
| WARRANTY AND CE: | |
| 36 moths warranty for the CNC and for all the electric parts of the machine | |
| 12-month warranty on machine mechanics | |
| CE compliance |
| MŰSZAKI SPECIFIKÁCIÓK | |
| WORKING AREA: | |
| Max. swing diameter over bed | 1800 mm |
| Maximum turning diameter | 1600 mm |
| Maximum turning length | 1200 mm |
| AXIS: | |
| Type of Guideway | Box type guide way |
| X stroke/travel | 1050 mm |
| Z stroke/travel | 900 mm |
| X / Z rapid travel speed | 45942 mpm |
| SPINDLE: | |
| Number of ranges | 1 |
| SPINDLE MOTOR: | |
| Spindle motor power | 37 / 45 kW |
| Spindle motor torque | 19000 Nm |
| SUBSPINDLE: | |
| TAILSTOCK: | |
| TOOLING: | |
| Tool change | Magazin with toolchanger |
| Number of tool positions | 16 pc |
| Tooling | BT50 |
| INSTALLATION: | |
| Floor space × height | 5790 × 4470 × 5300 mm |
| Net machine weight | 27000 kg |
| Electrical connection | 3 × 400 V AC VA |
| ALAPTARTOZÉKOK ÉS OPCIÓK | |
| category | 13 |
| RAM type | |
| Chain chip conveyor | |
| CONTROL AND ELECTRONICS: | |
| NCT 304 Controller 19" touchscreen | |
| 19" touchscreen | |
| SERVICES: | |
| OPTIONS: | |
NVL-160RM
RAM type vertical lathe with live tool
Fill out our form and our experts will help you find the most suitable solutions!
-
Vertical bed, Y axis CNC Lathe
-
Spacious working area, wide open working space door
-
Convenient operation, spacious workspace, wide-opening work door
-
Cast iron bed and slide system
-
Rigid cast iron bed and slide system
-
RAM-type design with tool magazine
-
RAM-type design with driven tooling and tool magazine
-
Hardened and precision ground box ways, the slide surface coated with TURCITE
-
Mounted, precision linear ball guideways on all axes
-
Telescopic metal guideway cover on every axis heads
-
Ground, high-precision double-nut ball screws
-
Direct coupling between servomotor and ballscrew by rigid clutch
-
Direct coupling between servomotor and supported in bearings at both ends
-
Central oil-lubricated slide system and ball screws
-
Headstock/spindle bearings with life long grease lubrication
-
Headstock range switch
-
BT50
-
without tailstock
CONSTRUCTION:
AXES:
SPINDLE:
CHUCK:
TOOLING:
TAILSTOCK:
